We provide an assessment of the Infinity Two Fusion Pilot Plant (FPP) baseline plasma physics design. Infinity Two is a four-field period, aspect ratio A = 10, quasi-isodynamic stellarator with improved confinement appealing to a max-J approach, elevated plasma density and high magnetic fields (⟨B⟩ = 9 T). At the envisioned operating point [800 MW deuterium-tritium (DT) fusion], the configuration has robust magnetic surfaces based on magnetohydrodynamic (MHD) equilibrium calculations and is stable to both local and global MHD instabilities. The configuration has excellent confinement properties with small neoclassical transport and low bootstrap current (|Ibootstrap| ∼ 2 kA). Calculations of collisional alpha particle confinement in a DT FPP scenario show small energy losses to the first wall (< 1.5%) and stable energetic particle/Alfvén eigenmodes at high ion density. Low turbulent transport is produced using a combination of density profile control consistent with pellet fueling and reduced stiffness to turbulent transport via three-dimensional shaping. Transport simulations with the T3D-GX-SFINCS code suite with self-consistent turbulent and neoclassical transport predict that the Pfus = 800 MW operating point is attainable with high fusion gain (Q = 40) at volume-averaged electron densities ne ≈ 2×1020 m−3, below the Sudo density limit. Additional transport calculations show that an ignited (Q = ∞) solution is available at slightly higher density (2.2×1020 m−3) with Pfus = 1.5 GW. The magnetic configuration is defined by a magnetic coil set with sufficient room for an island divertor, shielding and blanket solutions with tritium breeding ratios (TBR) above unity. An optimistic estimate for the gas-cooled solid breeder designed Helium Cooled Pebble Bed is TBR ∼ 1.3. Infinity Two satisfies the physics requirements of a stellarator fusion pilot plant.

In this work, we present a detailed assessment of fusion-born alpha-particle confinement, their wall loads, and stability of Alfvén eigenmodes driven by these energetic particles in the Infinity Two Fusion Pilot Plant Baseline Plasma Design, a 4-field-period quasiisodynamic stellarator to operate in deuterium-tritium fusion conditions. Using the Monte-Carlo codes SIMPLE, ASCOT5, and KORC-T, we study the collisionless and collisional dynamics of guiding-center and full-orbit alpha-particles in the core plasma. We find that core energy losses to the wall are less than 4%. Our simulations shows that peak power loads on the wall of this configuration are around 2.5 MW/m2 and are spatially localized, toroidally, and poloidaly in the vicinity of x-points of the magnetic island chain n/m = 4/5 outside the plasma volume. Also, an exploratory analysis using various simplified walls shows that shaping and distance of the wall from the plasma volume can help reduce peak power loads. Our stability assessment of Alfvén eigenmodes using the STELLGAP and FAR3d codes shows the absence of unstable modes driven by alpha-particles in Infinity Two due to the relatively low alpha-particle beta at the envisioned 800 MW operating scenario.

The magneto-hydrodynamic equilibrium and stability properties of the Infinity Two Fusion Pilot Plant baseline plasma physics design are presented. The configuration is a four field period, aspect ratio A = 10 quasi-isodynamic stellarator optimized for excellent confinement at elevated density and high magnetic field B = 9 T. Magnetic surfaces exist in the plasma core in vacuum and retain good equilibrium surface integrity from vacuum to an operational β = 1.6%, the ratio of the volume average of the plasma and magnetic pressures, corresponding to 800 MW Deuterium-Tritium fusion operation. Neoclassical calculations show that a selfconsistent bootstrap current on the order of ∼ 1 kA slightly increases the rotational transform profile by less than 0.001. The configuration has a magnetic well across its entire radius. From vacuum to the operating point, the configuration exhibits good ballooning stability characteristics, exhibits good Mercier stability across most of its minor radius, and it is stable against global low-n MHD instabilities up to β = 3.2%.

The selection, design, and optimization of a suitable blanket configuration for an advanced high-field stellarator concept is seen as a key feasibility issue and has been incorporated as a vital and necessary part of the Infinity Two Fusion Pilot Plant (FPP) physics basis. The focus of this work was to identify a baseline blanket which can be rapidly deployed for Infinity Two while also maintaining flexibility and opportunities for higher performing concepts later in development. Results from this analysis indicate that gas-cooled solid breeder designs such as the Helium Cooled Pebble Bed (HCPB) are the most promising concepts, primarily motivated by the neutronics performance at applicable blanket build depths, and the relatively mature technology basis. The lithium lead (PbLi) family of concepts, particularly the Dual Cooled Lithium Lead (DCLL), offer a compelling alternative to solid blanket concepts as they have synergistic developmental pathways while simultaneously mitigating much of the technical risk of those designs. Homogenized 3-dimensional neutronics analysis of the Infinity Two configuration indicates that the HCPB achieves an adequate tritium breeding ratio (TBR) (1.30 which enables sufficient margin at low engineering fidelity), and near appropriate shielding of the magnets (average fast fluence of 1.3 x 1018 n/cm2 per fullpower year). The thermal analysis indicates that reasonably high thermal efficiencies (greater than 30%) are readily achievable with the HCPB paired with a simple Rankine cycle using reheat. Finally, the tritium fuel cycle analysis for Infinity Two shows viability, with anticipated operational inventories of less than one kilogram (approximately 675 grams) and a required TBR (TBRreq) of less than 1.05 to maintain fuel self-sufficiency (approximately 1.023 for a driver blanket with no inventory doubling). Although further optimization and engineering design is still required, at the physics basis stage all initial targets have been met for the Infinity Two configuration.

An analysis of the divertor designs for the Infinity Two Fusion Pilot Plant (FPP) Baseline Plasma Design is presented. The divertor uses an m = 5, n = 4 magnetic island chain. Two divertor designs are presented. A classical divertor that is similar to the W7-X island divertor is analyzed using diffusive field line following and the fluid code EMC3-Lite. For a baseline 800 MW operating point in Infinity Two, the conditions where the heat flux on the divertor plate remains in the acceptable region are analyzed. In addition a related, but different and novel Large Island Backside Divertor (LIBD) design is shown. The LIBD promises improved neutral pumping by closing the divertor through the use of baffling and with a structure inside the island, thus preventing neutralized plasma particles from reentering the plasma.

Transport characteristics and predicted confinement are shown for the Infinity Two fusion pilot plant baseline plasma physics design, a high field stellarator concept developed using modern optimization techniques. Transport predictions are made using high fidelity nonlinear gyrokinetic turbulence simulations along with drift kinetic neoclassical simulations. A pellet fueled scenario is proposed that enables supporting an edge density gradient to substantially reduce ion temperature gradient turbulence. Trapped electron mode turbulence is minimized through the quasi-isodynamic configuration that has been optimized with max-J. A baseline operating point with deuterium-tritium fusion power of Pfus,DT = 800 MW with high fusion gain Qfus = 40 is demonstrated, respecting the Sudo density limit and magnetohydrodynamic stability limits. Additional higher power operating points are also predicted, including a fully ignited (Qfus = ∞) case with Pfus,DT = 1.5 GW. Pellet ablation calculations indicate it is plausible to fuel and sustain the desired density profile. Impurity transport calculations indicate turbulent fluxes dominate neoclassical fluxes deep into the core, and it is predicted that impurity peaking will be smaller than assumed in the transport simulations. A path to access large radiation fraction needed to satisfy exhaust requirements while sustaining core performance is also discussed.
